型號

流量
Q
(m^3/h)

揚程
H
(m)

轉速
n
(r/min)

軸功率
Pa
(kw)

效率
η
(%)

氣蝕余量
(NPSH)r
m

配帶電動機型號功率

輸送介質比重 g/cm^3

≤1

≤1.3

≤1.84

IMC50-32-125

7.5
12.5
15

22
20
18.5

2900

1.49
1.62
1.63

30
42
43

3.5
3.5
4.0

Y
YB90L-2
2.2

Y
YB100L-2
3.0

Y
YB112M-2
4.0

IMC50-32-160

7.5
12.5
15

34
32
29

2900

2.48
2.79
2.96

28
39
40

3.5
3.5
4.0

Y
YB100L-2
3.0

Y
YB112M-2
4.0

Y
YB132S1-2
5.5

IMC50-32-200

7.5
12.5
15

52.5
50
48

2900

5.10
5.49
6.13

21
31
32

2.5
2.5
3.0

Y
YB132S2-2
57.5

Y
YB132S2-2
7.5

Y
YB160M1-2
11

IMC50-32-250

7.5
12.5
15

22
20
18.5

2900

9.57
10.89
13.32

17.5
25
26

3.5
3.5
4.0

Y
YB160M2-2
15

Y
YB160L-2
18.5

Y
YB180M-2
22

IMC65-50-125

15
25
30

22
20
18.5

2900

2.25
2.67
2.91

40
51
52

3.5
3.5
4.0

Y
YB100L-2
3.0

Y
YB112M-2
4.0

Y
YB132S1-2
5.5

IMC65-50-160

15
25
30

34
32
29.5

2900

4.34
5.07
5.48

32
43
44

3.5
3.5
4.0

Y
YB132S1-2
5.5

Y
YB132S2-2
7.5

Y
YB160M1-2
11

IMC65-40-200

15
20
30

53
50
47

2900

8.66
9.20
10.1

25
37
38

3.5
3.5
4.0

Y
YB160M1-2
11

Y
YB160M2-2
15

Y
YB160L1-2
18.5

IMC65-40-250

15
25
30

82
80
78.5

2900

13.4
14.72
16.88

25
37
38

3.5
3.5
4.0

Y
YB160L-2
18.5

Y
YB180M-2
22

Y
YB200L1-2
30

IMC65-40-315

15
25
30

127
125
123

2900

27.33
27.44
30.44

19
31
33

3.5
3.5
4.0

Y
TB200l2-2
37

Y
YB225M-2
45

Y
YB280S-2
75

IMC80-65-125

30
50
60

22.5
20
18

2900

4.48
5.24
5.55

41
52
53

4.0
4.0
4.5

Y
YB132S1-2
5.5

Y
YB132S2-2
7.5

Y
YB160M1-2
11

IMC80-65-160

30
50
60

34
32
29

2900

7.72
9.08
9.67

36
48
49

4.0
4.0
4.5

Y
YB160M1-2
11

Y
YB160M2-2
15

Y
YB160L1-2
18.5

IMC80-50-200

30
50
60

53
50
47

2900

12.03
14.80
16.34

36
46
47

4.0
4.0
4.5

Y
YB160M1-2
11

Y
YB160M2-2
15

Y
YB160L1-2
18.5

IMC80-50-250

30
50
60

84
80
75

2900

19.06
23.68
26.07

36
46
47

4.0
4.0
4.5

Y
YB200L1-2
30

Y
YB200L2-2
37

Y
YB225M-2
45

IMC80-50-315

30
50
60

128
125
123

2900

36.05
40.56
44.75

29
42
45

4.0
4.0
4.5

Y
YB250M-2
55

Y
YB280S-2
15

Y
YB280M-2
90

IMC100-80-125

60
100
120

23
20
16.5

2900

8.35
9.73
9.46

45
56
57

4.0
4.0
4.5

Y
YB160M1-2
11

Y
YB160M2-2
15

Y
YB160L-2
18.5

IMC100-80-160

60
100
120

35
32
28

2900

12.43
15.85
16.34

46
55
56

4.0
4.0
4.5

Y
YB160L-2
18.5

Y
YB180M-2
22

Y
YB200L1-2
30

IMC100-65-200

60
100
120

54
50
47

2900

21.01
25.69
28.44

42
53
56

4.0
4.0
4.5

Y
YB200L1-2
30

Y
YB200L2-2
37

Y
YB225M-2
45

IMC100-65-250

60
100
120

89
80
74.5

2900

37.98
45.39
49.69

37
48
49

4.0
4.0
4.5

Y
YB255M-2
45

Y
YB250M-2
55

Y
YB280S-2
75
